產(chǎn)品特性
| Part Number | Power Switch | IOH/IOL (A) | Output VCC/VDD (V) | Input VCC (V) | Prop. Delay（ns） | Input Config | Program Deadtime | Overlap Protection | CMTI (kV/μs) Min. | VISO(Vrms) | Operating Temp （℃） | Package Group | Packing/QTY |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SLMi8230BDCG-DG | IGBT/MOSFET/SiC/GaN | 1.0/1.5 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8230DDCG-DG | IGBT/MOSFET/SiC/GaN | 1.0/1.5 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8231BDCG-DG | IGBT/MOSFET/SiC/GaN | 1.0/1.5 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8231DDCG-DG | IGBT/MOSFET/SiC/GaN | 1.0/1.5 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8232BDCG-DG | IGBT/MOSFET/SiC/GaN | 1.0/1.5 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8232DDCG-DG | IGBT/MOSFET/SiC/GaN | 1.0/1.5 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233BDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233DDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234BDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234DDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235BDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235DDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233HBDCP-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8233HDDCP-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8234HBDCP-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8234HDDCP-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8235HBDCP-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8235HDDCP-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8233HBDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233HDDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234HBDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234HDDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235HBDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235HDDCG-DG | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233BDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233DDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234BDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234DDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235BDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235DDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233HBDCP-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8233HDDCP-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8234HBDCP-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8234HDDCP-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8235HBDCP-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8235HDDCP-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8233HBDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8233HDDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234HBDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8234HDDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235HBDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8235HDDCG-AQ | IGBT/MOSFET/SiC/GaN | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8253CBDCG-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8253CDDCG-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8254CBDCG-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8254CDDCG-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8255CBDCG-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8255CDDCG-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SLMi8253CBDCP-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8253CDDCP-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8254CBDCP-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8254CDDCP-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8255CBDCP-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8255CDDCP-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 5000 | –40 ~ 125 | SOP14W | Reel/1500 |
| SLMi8253CBBCL-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 3000 | –40 ~ 125 | SOP16 | Reel/3000 |
| SLMi8253CDBCL-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | Y | Y | 100 | 3000 | –40 ~ 125 | SOP16 | Reel/3000 |
| SLMi8254CBBCL-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | PWM | Y | Y | 100 | 3000 | –40 ~ 125 | SOP16 | Reel/3000 |
| SLMi8254CDBCL-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | PWM | Y | Y | 100 | 3000 | –40 ~ 125 | SOP16 | Reel/3000 |
| SLMi8255CBBCL-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 9-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 3000 | –40 ~ 125 | SOP16 | Reel/3000 |
| SLMi8255CDBCL-DG | IGBT/MOSFET/SiC | 4.0/7.0 | 13.5-40 | 3-18 | 40 | VIA/VIB | - | - | 100 | 3000 | –40 ~ 125 | SOP16 | Reel/3000 |
