產品特性
| Part Number | Power Switch | IOH/IOL (A) | Output VCC/VDD (V) | Input VCC (V) | Prop. Delay（ns） | Split Out | ASC | Soft Turn Off | CMTI (kV/μs) Min. | VISO(Vrms) | Operating Temp （℃） | Package Group | Packing/QTY |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SiLM5851NHCG-DG | IGBT/SiC | 3.0/6.0 | 13-30 | 3-5.5 | 90 | - | - | - | 150 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SiLM5852SHCG-DG | IGBT/SiC | 3.0/6.0 | 13-30 | 3-5.5 | 90 | Y | - | Y | 150 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
| SiLM5852SHCG-AQ | IGBT/SiC | 3.0/6.0 | 13-30 | 3-5.5 | 90 | Y | - | Y | 150 | 5000 | –40 ~ 125 | SOP16W | Reel/1500 |
